| 5,40 € 4,86 € |
With the new compression fittings from Alphacool for Plexi, brass, borosilicate glass, or carbon tubes, Alphacool is taking a further step towards perfection and quality.
The first two colours, chrome and deep black, offer great variety. The fully coordinated product series allows each system to shine in its own right, and individuality has no limits when paired with the Alphacool Plexi and brass tubes!
The colouring is bound fast to the brass surface with a new chromatization process. This ensures the longevity of the intense colour and prevents chipping of the chrome layer. An Alphacool logo on the connector emphasizes the distinctive nature of this product once again.
The Function of this Connector is:
This connector is used to connect two 13mm Plexi, brass, borosilicate glass, or carbon tubes at a 90° angle.
Dimensions:
Technical Details:
Scope of Delivery:
EK-Torque HDC 12 fittings are EK's new minimalistic 12mm hard-tube compression fittings designed for use with solid tubing such as Acrylic and PETG. With a non-intrusive, yet striking look, and with NO added branding at all. They can be complemented by interchangeable aesthetic color rings, and are an ideal choice for anyone and a perfect match with EK-Quantum series products.
The locking ring prevents solid tube to be pulled out of the fitting by compressing the rubber gasket underneath the ring. The grooves on the outside allow for easier hand tightening. The compression ring has cutouts in EK Quantum signature shape allowing for the colored aesthetic ring to be shown. The colored rings are available in many colors and are screwed onto the fitting before the compression locking ring. The aesthetic rings are sold separately.
The fitting barb and the compression rings are covered with a unique, high-quality nickel finish. Both are made of CNC machined brass and the seal is made quality rubber O-rings.
The base fitting surface is smooth and has no adequate gripping surface, but the inside of the barb is socketed with a 9mm hex Allen key pattern. It's highly recommended to use an Allen Key 9mm (purchased separately) to prevent skin damage to the fingertips while installing the fitting. Please, be advised not to use excessive force when attaching fitting barbs using Allen Key 9mm in order to prevent damage to other liquid cooling products!
These fittings are guaranteed to be compatible with all other EK Water Blocks liquid cooling products.
Technical data:
- Finish: Satin silver
- Thread: G1/4" BSP; 4.5mm male thread length
- Supported tube: 12mm OD
- The outer diameter of a fitting: 20mm
- Installed height: 15mm
- Compatible solid tubing: Acrylic, PETG, Copper, Brass, Stainless Steel
Made in Europe - Slovenia!
