EK Water Blocks EK-FC970 GTX TF5 - Nickel

EK-FC970 GTX TF5 is a high performance full-cover water block for MSI non-reference design NVIDIA GeForce GTX 970 series graphics cards. Please check our Cooling Configurator online compatibility system for detailed compatibility list!

This water block directly cools the GPU, RAM as well as VRM (voltage regulation module) as water flows directly over these critical areas thus allowing the graphics card and it's VRM to remain stable under high overclocks.

EK-FC970 GTX TF5 water block features a central inlet split-flow cooling engine design for best possible cooling performance, which also works flawlessly with reversed water flow without adversely affecting the cooling performance. Moreover, such design offers great hydraulic perfromance allowing this product to be used in liquid cooling systems using weaker water pumps.

Base is made of nickel-plated electrolytic copper while the top is made of quality acrylic glass. The sealing is ensured by quality rubber washers. Screw-in brass standoffs are pre-installed and allow for safe, painless installation procedure. Block is mounted with enclosed M3x4 DIN7985 screws and washers.

EKWB recommends the purchase of aesthetic retention backplate (EK-FC970 GTX TF5 Backplate - Black or Nickel) which improves the looks of your graphics cards and also provide some passive cooling to the memory IC on the backside of the circuit board.

G1/4" threaded fittings can be used on both sides of the FC terminal. Up to four EK-FC970 GTX TF5 water blocks can be used on a single ATX form factor motherboard by using EK-FC Terminal (DUAL, TRIPLE or QUAD type) system or other means of interconnectivity. Please note that EK-FC Bridge & Link system is not compatible with this water block.

Enclosed:
- EK-FC970 GTX TF5 water block
- mounting mechanism with screw-in brass standoffs
- thermal pads
- thermal grease EK-TIM Ectotherm (1g)

PLEASE NOTE:
- Due to immense variety of fittings/barbs available on market and no prescribed standards, we guarantee compatibility only for connectors bought from our web site.
