| 79,90 € 71,91 € |
Alphacool's new Laing Low Noise Edition for absolute silence!
The well-known Laing DDC pumps are getting a new addition. Though freshly packaged, this pump can begin its life with lots of self-confidence. A few details have been changed. First, we held back a little in performance in order to solve a widespread problem: the volume! Few other pumps can match this one in terms of reducing noise generation from water. For the most up-to-date water cooling systems with CPU and GPU cooling, this pump should be the first choice.
Unlike before, this pump does not come in the familiar plastic casing. It has an all-new perfectly tailored brass case gracing its exterior. This new case ensures a longer lifespan for the pump. Air flows through the cooling fins, then over an interior thermal pad directly to the pump board.
Another feature is the included decoupling option. With the special M4 screws, the included decoupling can be screwed into the head of the screws and then attached to the case.
The innovation in this set is that it uses the V.2 of the Alphacool "Eisdecken", which provides you the options of three G1/4" connections for the inlet and two G1/4" connections for the outlet.
Inlet options: front, side, top
Outlet options: front, top
The scope of delivery also includes three G1/4" screw plugs for sealing the unused in/out connection ports.
Another feature is the pre-installed brackets, as seen before on the new "Eisbecher". This allows the pump set to be mounted directly onto the case bottom.
Now available as a combo with the tried and tested Alphacool Eisdecke Laing DDC Plexi or Acetal Top!
Technical Details:
Scope of Delivery:
The Alphacool Apex Distro Plate is the visual upgrade for the Y60. It was specially designed for this case and replaces the front glass panel. A must-have for every custom water cooling system.
Apex Design
The Apex product line from Alphacool represents the highest level of perfection. First-class materials and innovative technologies guarantee a unique premium product. A core element is the chrome-plated brass G1/4" connections. In this way, Alphacool avoids the problem of possible leaks due to cracking caused by screwing the connections directly into the acrylic. The connections are in two parts, fitted with an O-ring and counter each other when installed in the acrylic.
High-quality choice of materials & brilliant lighting
Alphacool's Apex Distro Plate is made from high-quality acrylic glass. This allows a clear view of the coolant and enables brilliant illumination thanks to the built-in digitally addressable aRGB lighting. The lighting can be controlled via a digital aRGB header on the mainboard or optionally via Alphacool's Aurora Eiscontrol aRGB controller (article no.: 15360).
Easy installation
The Alphacool Apex Distro Plate Y60 replaces the front glass panel of the Y60 housing and is easy to install. It is mounted in place of the glass panel and securely fastened using the original screws. After installation, the distro plate is connected to the water cooling loop.
Note: The Apex Distro Plate Y60 is only compatible with the Y60 housing.
Attention: It is not possible to mount the Distro Plate if a 140 mm or 280 mm radiator is attached to the side.
Compatibility:
- Y60 Case
Technical data
Dimensions (L x W x H)
344,50 x 213,50 x 87,30 mm
Material
acrylic
Volume
approx. 300ml
Pump compatibility
VPP/D5
Threads
6x G1/4" + 1x fill port and 1x drain port
Maximum working temperature
60 °C
Pressure tested
0,8 Bar
Quantity digital aRGB LEDs
11
Power digital aRGB LEDs
5V
Power connection digital aRGB LEDs
3-Pin JST + 3-Pin 5V
Weight
3000g
Color
transparent
Technical data pump
Material pump
synthetic material
Material pump cover
aluminium
Material axle
ceramics
Connections
4-Pin PWM | SATA
Rotational speed
2500 - 4500 RPM
Cable lengths
4-Pin PWM - 48cm | SATA - 48cm
Operating voltage
8-13V DC / 14W IP32
Starting voltage
12V DC
Maximum pumping head
4,25m
Maximum flow rate
340L/h
Maximum working temperature
60°C
Color
black
Note on application
Please use only in conjunction with clear transparent water cooling fluids. The particles and additives in Pastel liquids can clog and permanently damage water cooling products such as radiators, pumps, coolers and hoses. This can result in voiding the manufacturer's warranty as well.
