| 129,90 € 116,91 € |
The Barrow BS-MSV5090-PA is a premium full-cover GPU water block, specifically designed for MSI RTX 5090 VENTUs & Inno3D RTX 5090 Dark Knight X3 series graphics cards. Built using a solid 10mm thick CNC-machined copper base with anti-oxidation nickel plating, this water block delivers exceptional cooling performance for the GPU core, memory modules, power MOSFETs, and other critical components.
Enhanced with high-density microchannels, a patented bridge structure, and a transparent imported acrylic top, it ensures outstanding heat transfer, long-term durability, and brilliant ARGB lighting. Standard with an aluminum alloy backplate for added PCB protection, the BS-MSV5090-PA is the ultimate upgrade for gamers and PC enthusiasts demanding top-level thermal performance and customizable visual appeal.
Key Features:
- Full-Coverage Cooling: Actively cools the GPU core, memory RAM, power supply MOS, inductance, and tantalum capacitors.
- Micro Water Passage Design: Dense microchannels maximize surface area contact and enhance heat dissipation efficiency.
- 10mm Thick Copper Base: Ultra-thick copper with nickel plating improves structural integrity and optimizes thermal conductivity.
- Three-Layer Cooling Structure: Specialized cold-finger core design for maximum GPU core heat absorption and cooling.
- Imported High-Transparency Acrylic Top: Brilliant lighting transmission with no yellowing or cracking over time.
- Integrated Patent Bridge: Ensures sealing stability and boosts water flow coverage for optimal performance.
- ARGB Lighting Support: Compatible with major motherboard 5V ARGB systems including ASUS Aura Sync, Gigabyte RGB Fusion 2.0, MSI Mystic Light, and ASRock Polychrome Sync.
- Included Aluminum Alloy Backplate: Protects the PCB and enhances rigidity while aiding in passive cooling.
- Easy Maintenance: Modular RGB components can be replaced or upgraded easily.
VGA Card Compatibility:
- MSI RTX 5090 D 32G VENTUS 3XOC
- MSI RTX 5090 D 32G VENTUS 3X
- Inno3D GeForce RTX 5090 Dark Knight X3
Included:
1x GPU water block & white backplate
Complete hardware
Thermal Pads
For motherboards equipped with a 5V A-RGB connector, use this adapter: ZBDZJX-5
The next generation - the Alphacool Eisblock Aurora water cooler for Geforce RTX 4XXX graphics cards. In order to dissipate the enormous heat of this graphics card generation in the best possible way, numerous optimizations have been made to the water cooler compared to the previous model. The fin structure was adapted and enables a very good water flow while increasing the cooling surface. The modified jet plate with improved inflow engine ensures an optimal distribution of the water on the cooling fins.
Important note: The RTX 4090 Eisblock Aurora Reference cooler is not compatible with Nvidia's Geforce RTX 4090 Founders Edition. The RTX 4090 FE is compatible with the following cooler: Alphacool Eisblock Aurora Acryl GPX-N RTX 4090 Founders Edition with Backplate (Art. 15632)
Technical Highlights
The fin structure of this Eisblock cooler generation was developed together with Nvidia board partners. The fin thickness is 0.4 mm, the distance between the cooling fins is 0.4 mm. This ensures a very good water flow while increasing the cooling surface. The jet plate has a revised inlay that spreads the water pressure better over the fins thus optimizing the heat absorption. The adjusted water inflow gives the water a better angle of inflow.
Chrome-plated copper
The cooler is made entirely of chrome-plated copper. A chrome plating is much harder than a nickel plating and therefore less sensitive to acids, scratches and damage. It completely eliminates the risk of chipping nickel plating. Additionally, chrome plating looks much more homogeneous and provides a shine that cannot be achieved by nickel plating. Chrome-plated coolers have previously only been used in the industrial sector in areas where extreme influences act on the coolers.
Design
The Aurora design of the Geforce RTX 4XXX Eisblock generation is visually calmer and simpler. Only one O-ring runs around the entire cooler. The design around the cooling fins and jetplate makes for a cleaner look. The illumination of the digitally addressable RGB LEDs is even better distributed throughout the cooler as a result of the chrome plating. The terminal's design is in line with the classic Aurora design.
Thermal paste & thermal pads
The included thermal compound is Alphacool's Subzero. With a thermal conductivity of 16 W/mk, it is one of the highest performing thermal pastes on the market. The electrically non-conductive thermal compund is particularly well suited for high contact pressures, but can still be processed perfectly due to its viscosity of 850000 TF. Alphacool Soft Pads with 1mm thickness are used on the voltage converter and the graphics memory. The thermal conductivity of the pads is 7W/mk. The pads for the back of the PCB are 3mm thick and have a thermal conductivity of 3W/mk.
Compatibility:
| Technical data cooler | |
| L x W x H | 198,60 x 144,29 x 35,89mm |
| Material cooler | chrome-plated copper |
| Material cooler top | acrylic |
| Threads | 4 x G1/4" |
| Thickness cooling fins | 0,4mm |
| Distance cooling fins | 0,4mm |
| Illumination | digital aRGB LEDs |
| Power connector digital aRGB LEDs | 3-Pin JST |
| Power digital aRGB LEDs | 5V |
| Number of digital aRGB LEDs | 12 |
| Technical data backplate | |
| L x W x H | 198,60 x 119,69 x 6mm |
| Material | aluminium |
| Color | black |
Note on application
Please use only in conjunction with clear transparent water cooling fluids. The particles and additives in Pastel liquids can clog and permanently damage water cooling products such as radiators, pumps, coolers and hoses. This can result in voiding the manufacturer's warranty as well.
