The Barrow BS-ASA5090-PA is a premium full-cover GPU water block, specifically designed for ASUS ROG Astral RTX 5090 series graphics cards. Built using a solid 10mm thick CNC-machined copper base with anti-oxidation nickel plating, this water block delivers exceptional cooling performance for the GPU core, memory modules, power MOSFETs, and other critical components.
Enhanced with high-density microchannels, a patented bridge structure, and a transparent imported acrylic top, it ensures outstanding heat transfer, long-term durability, and brilliant ARGB lighting. Standard with an aluminum alloy backplate for added PCB protection, the BS-ASA5090-PA is the ultimate upgrade for gamers and PC enthusiasts demanding top-level thermal performance and customizable visual appeal.
Key Features:
- Full-Coverage Cooling: Actively cools the GPU core, memory RAM, power supply MOS, inductance, and tantalum capacitors.
- Micro Water Passage Design: Dense microchannels maximize surface area contact and enhance heat dissipation efficiency.
- 10mm Thick Copper Base: Ultra-thick copper with nickel plating improves structural integrity and optimizes thermal conductivity.
- Three-Layer Cooling Structure: Specialized cold-finger core design for maximum GPU core heat absorption and cooling.
- Imported High-Transparency Acrylic Top: Brilliant lighting transmission with no yellowing or cracking over time.
- Integrated Patent Bridge: Ensures sealing stability and boosts water flow coverage for optimal performance.
- ARGB Lighting Support: Compatible with major motherboard 5V ARGB systems including ASUS Aura Sync, Gigabyte RGB Fusion 2.0, MSI Mystic Light, and ASRock Polychrome Sync.
- Included Aluminum Alloy Backplate: Protects the PCB and enhances rigidity while aiding in passive cooling.
- Easy Maintenance: Modular RGB components can be replaced or upgraded easily.
VGA Card Compatibility:
- ASUS TUF GAMING RTX 5080 016G GAMING
- ASUS TUF GAMING RTX 5080 16G GAMING
- ASUS TUF RTX 5070TI 016G GAMING
- ASUS TUF RTX 5070TI 16G GAMING
Included:
1x GPU water block & white backplate
Complete hardware
Thermal Pads
For motherboards equipped with a 5V A-RGB connector, use this adapter: ZBDZJX-5
This is the 2nd generation Vector GPU water block from the EK® Quantum Line, designed for EVGA® FTW3 RTX 3070 and FTW3 RTX 3070 Ti graphics cards based on the latest NVIDIA® Ampere™ architecture. For a precise compatibility match of this water block, we recommend you refer to the EK Cooling Configurator.
EK-Quantum Vector FTW3 3070 Ti D-RGB water block is compatible with FTW3 RTX 3070 and 3070 Ti graphics cards. The Vector water block actively cools the GPU, VRAM, power stages, and chokes in the VRM (voltage regulation module).
These newly developed water blocks feature optimized flow paths that reduce hydrodynamic instabilities and vortexing (dead spots) inside of them.
The EK-Quantum Vector Series water blocks use an Open Split-Flow cooling engine design, which proved to be a superior solution for GPU water blocks. It is characterized by low hydraulic flow restriction, meaning it can be used with weaker water pumps or pumps running on low-speed settings, and still achieve top performance. The jet plate and fin structure geometry have been optimized to provide even flow distribution with minimal losses and optimal performance when used in any given coolant flow orientation.
The base of the block is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of durable POM acetal. These 2nd generation Vector GPU water blocks also feature Acetal terminals. The watertight sealing is ensured by high-quality EPDM O-rings, while brass standoffs are already pre-installed and allow for a safe and easy installation procedure.
The aesthetic corner end-piece is housing the addressable D-RGB LEDs. This water block boasts a total of 8 individually addressable RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header.
EK recommends the purchase of a retention backplate, especially for the 3070 models of graphics cards. The backplate improves the overall aesthetics of your graphics cards and also provides additional passive cooling for the GPU core, and backside of the printed circuit board VRM section.
Enclosed:
- EK-Quantum Vector FTW3 RTX 3070 Ti D-RGB series high-performance water block
- Mounting mechanism with screw-in brass standoffs
- Necessary mounting screws, nuts, and washers
- 2x Nickel plated brass plug G1/4”
- EK-Loop Multi Allen Key (6mm, 8mm, 9mm)
- Thermal pads
- Thermal grease EK-TIM Ectotherm (1g)
Technical Specification:
- Dimensions: (LxHxW) - 314x155x21mm
