EK-Quantum Magnitude sTRX4 - Nickel + Acetal is the newest flagship CPU water block tailor-made for AMD® Ryzen™ Threadripper™ processors. The Magnitude sTRX4, which belongs to the EK-Quantum product line, is the most complex Threadripper CPU water block on the market to date. This new lineup has no intention of succeeding or replacing their Velocity sTR4 counterparts, as the Magnitude version is a rather sophisticated alternative optimized specifically for Zen 2 based AMD Threadripper CPUs.
The award-winning, signature design truly sets the Magnitude apart, with every piece being CNC-milled from a solid piece of material. The precisely machined flat coldplate is made of nickel-plated high-grade copper and the top is made of durable black POM Acetal. The three-dimensional black-anodized aluminum mounting frame perfectly blends in with the asymmetrical shape of the Threadripper CPU socket, while making the screws a seamless part of the water block. Strong edges and chamfers root this futuristic design firmly into the EK Quantum line. Magnitude proudly bears the prestigious iF Design Award.
It is possible to rotate the Insert by 180°, thus exchanging the optimal inlet and outlet ports so that the flow direction may be reversed. Because the SP3 sockets are asymmetrical, and to prevent incorrect re-assembly, it is not possible to rotate the top, frame, or coldplate relative to the socket. The accents in a different color are available separately and can easily be replaced.
The water block implements the evolution of the patent-pending technology called TDC, or Targeted Die Cooling. This technology was first developed for the 2nd generation EK Threadripper CPU water blocks. The Magnitude now utilizes it on a more sophisticated level. The cooling engine is enlarged significantly. The coldplate is now completely flat with the 4 patches that ensure optimal contact with the IHS over CCDs creating ideal conditions for best thermal transfer. Two 0.5mm thick jet plates make sure that coolant flow is focused and turbulent over the CCDs (Core Complex Dies).
This product is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin LED connector is to be aligned with the +5V marking on the addressable RGB header. The Nickel + Acetal version uses the same high-density LED strip with a total of 44 addressable RGB diodes as the other LED-lit Magnitude water blocks, and they illuminate outwards through the milky white frame. The LED Strip must be inserted through the frame and the wire can exit the block on any of the corners for best cable routing.
CPU socket compatibility:
- AMD Socket sTRX4 (Socker SP3r3)
- AMD Socket TR4 (Socket SP3r2)
- AMD Socket SP3
Enclosed:
- EK-Quantum Magnitude sTRX4 D-RGB - Nickel + Acetal water block
- TIM / thermal grease: EK-TIM Ectotherm (1g)
EK-Quantum Momentum Aorus Z490 Master D-RGB is the new Quantum Line monoblock specifically engineered for the Gigabyte® Aorus Z490 Master motherboard. Featuring the latest generation Velocity cooling engine with low restriction and high performance, this monoblock is equipped with a 3-pin D-RGB (addressable) LED strip and it offers unparalleled aesthetical customization alongside superior performance! The D-RGB LED in the monoblock is compatible with Gigabyte RGB Fusion 2.0 which offers a full lighting customization experience.
EK® Momentum series monoblocks utilize the 5th generation of the award-winning EK® CPU water block cooling engine, further tweaked for performance and optimal coolant flow! This water block directly cools Intel® 1200 socket-type CPU, as well as the power regulation (MOSFET) module. Liquid flows directly over all critical areas, providing the enthusiasts with a great solution for high and stable overclocks. Like with every EK monoblock, the EK-Quantum Momentum Aorus Z490 Master features a high flow design and it can be easily used with the system using weaker water pump or lower pump speed settings as well. The Momentum monoblock also comes with sophisticated addressable D-RGB lightning which connects to a standard 3-pin 5V D-RGB header on the motherboard.
The purest nickel-plated copper available on the market is used for the cold plate which is precisely machined to a dense micro-fin structure. The nickel-plated brass screw-in standoffs are pre-installed and allow for easy installation. Top of the monoblock features a CNC machined glass-like cast acrylic top piece.
The new cooling engine is characterized by the top-integrated jet nozzle which is combined with a thicker jet plate allowing a more precise bow control. The simplified water block structure offers a more optimized coolant flow and easier maintenance, while the jet plate ensures the best contact surface for the CPU.
Unlike other solution on the market, this is a true one-piece, sturdy and reliable liquid cooling product which requires only two connector fittings for proper operation. The enclosed thermal pad is used on voltage regulator modules to improve stability, performance, and prolongs the lifespan of the motherboard. For the CPU, please use the enclosed (electrically non-conductive) thermal grease EK-TIM Ectotherm.
The block is already equipped with 3-pin 5V Addressable D-RGB LED strip which is compatible with the Aorus Z490 Master 3-pin 5V D_LED (Addressable LED Strip) headers. This product is also compatible with D-RGB controllers that support the pinout: +5V, D, Blocked, Ground. The arrow marking on the 3-pin LED connector is to be aligned with the +5V marking on the D_LED (Addressable LED Strip Headers)
Technical specifications:
- D-RGB connector 3-pin 5V digital LED header (Pinout: +5V, D, Blocked, Ground)
Enclosed:
- EK-Quantum Momentum Aorus Z490 Master D-RGB Monoblock
- Mounting mechanism
- Thermal grease EK-TIM Ectotherm
- Thermal pads
Made in Slovenia - Europe!
