| 74,90 € 67,41 € |
Features:
- Dual pass radiator designed for computer liquid cooling
- High liquid and air flow design
- Copper fin spacing optimized for high flow fans
- Slim height for easy mounting
- Perfect for all overclocking and silent projects
- Integrated OLED LCD Screen
Technical details:
Material: Copper fins, Brass Tubes, POM End Tanks, Aluminium Alloy Shroud (does not contact coolant)
Fins spacing: 18 FPI (Fins Per Inch)
Max pressure: 0.32 Bar
Dimensions: 272.8 x 120.8 x 30mm
Tube: 12 x 1.9mm Flat tubes
Connection threads: 2x G1/4”
Fan screw size: M3
Weight: 550g
Included:
1x BarrowCH Chameleon Fish 240P V2 OLED Copper Radiator (2x120mm) - Black / Black
M3 Mounting screws
The first compact and high-tech fan with bionic blade rotor of patented German technology.
Developed by Dr. Rudolf Bannasch with the support of the Federal Ministry of Economics and Bionics, the fans of the NB-ELOOP series are currently the most advanced in the world in terms of efficiency.
The NB-ELOOP series set new records in almost all categories and convinced by its technical qualities.
New NB cable management and 12 anti-vibration mounting parts make this a unique cooling system.
Technical characteristics :
Product reference: B12-P
Dimensions: 120x120x25mm
Weight: 123 g
Rated voltage: (V): 12V
Starting Voltage (V): 5.4V
Operating voltage (V): 3.9 - 13.8V
Input power (Watt): 1.92 Watt (12V)
TPM (12V): 800-2000 (+/- 10%)
Static pressure (12V): - 2,240 mm H2O (12V)
Air flow: (m3 / h): 132.4 m3 / h
Noise pollution (dB / A): <28.4 dB / A
MTBF life (25 ° c): 120,000 h (Std.)
Operating temperature: -10 ° ~ + 60°
Bionic frame and blades
NB-EKA 2 controls
NB-NanoSLI with double magnetic bearings
NB Cable Management
12-piece anti-vibration mounting system
20 + 50cm molex 3-pin adapter cable
4 pins PWM connector
